Digital Headend IP Gateway HD Satellite Receiver Up To 24 Tuners
Input
Product Description:
HMVMT03 is specially dsigned for vehicle-mounted application, could transmit
high resolution video in city or on sea where appears multipath
effect always.It can realise wide signal coverage without
directional antenna depend on its excellent "Diffract" ability .
It can simultaneously transmit one way image, one way Full-duplex
bidirectional audio and data.
Product Vantage
This is an ideal solution for environments where you have a large
number of air Channel, and widely used in IPTV System, Hotel,
entertainment facilities, education broadcasting systemsat schools
and government buildings or any kinds of Source signals convert to
Cable TV broadcast System, largely cost down the source gathering
of Digital TV Broadcasting system and IPTV/OTT system which based
on IP construction. Being the ideal multi-channel professional
receiver used for FTA (free to air) IP signal source capture from
digital tuner.
Product Sell Point:
1. Wide coverage and stable transmission with omni-directional antenna.
2. Rack mountable design, can be installed in a car or helicopter.
3. The product shell is made of high quality stainless steel which is
more solid and anti-deformation
4. Excellent anti-interference performance under complex
electromagnetic condition.
5. The LOS transmitter range can reach 150KM when worked with omni
high gain antenna.
6. Space diversity reception.
7. Can stably transmitter video&audio signal under the
condition of high-speed mobile and multipath interference.
Transmitter Picture:
Transmitter HMVMT03 Specification:
| General Part: |
| Work Frequency: | 300MHz-5.8GHz (customized) |
| Output power: | 30W/50W (option) |
| Modulation: | COFDM 2K QPSK/TDS-OFDM |
| Channel bandwidth: | 1.25/2/4/6/8MHz(adjustable) |
| Code stream: | 0.8Mbps~10Mbps |
| End to end delay: | <150ms |
| Error rate: | ≤10-6 |
| FEC: | Viterbi (1/2,2/3,3/4) |
| Guard interval: | 1/32,1/16,1/8,1/4 |
| Encryption: | AES/ABS(128bit) |
| Power supply: | AC220V/DC27V |
| Transmit distance: | On board application>150km;Marine application >70km;City
application>20km;Suburban application> 40km |
| Audio&Video Part: |
| Video Compression: | Conform to H.265,H.264,MPEG-2,MPEG-4 |
| Video input: | HDMI or SDI |
| AV Input | One way or multipath AV input are optional |
| AV Data format : | MPEG-2,MPEG-4 @ ML 4:2:0 |
| Audio input: | Left right sound channel |
| Resolution: | 1080P(1920*1080)compatible with 720× 576@ transmit rate is 30fps. |
| Two way voice: | Two way voice is optional |
| Others: |
| Antenna: | Omnidirectional antenna |
| Usage: | Vehicle-mounted,On board application |
| Weight: | 5.0kg |
| Appearance: | 2U,19inch crate |
| Cloud deck: | Cloud deck can be reversely controlled (Optional) |
| Size: | 480mm×220mm×45mm(L × W ×H) (1U) |
| Work temperature: | Temperature:-30~70℃ Relative humidity:90% |
| Reserve temperature: | Temperature: -40~80℃ Relative humidity:90% |
Receiver HMRMR01 Specification:
| General Part: |
| Work frequency: | 300MHz-399MHz,400MHz-5.8GHz (customized) |
| Frequency Spectrum: | The frequency spectrum function is available |
| TALLY System: | TALLY system(Optional) |
| Receive sensitivity: | -106dB |
| Power supply: | AC 220V |
| Audio&Video Part: |
| Video output: | HDMI, SDI,AV,RJ45 |
| Audio output: | Two way |
| Video compression: | H.265,H.264, MPEG-2@ ML 4:2:2 compatible with 4:2:0 |
| Video rate: | 25-30F/S |
| Resolution: | 1920*1080 compatible with 720×620 |
| Two way voice: | Two way voice is optional |
| Others: |
| Weight: | 2.0kg |
| Size: | 1U,19inch crate (480mm×220mm×45mm(L × W ×H) |
| Interface: | One way SD-SDI interface(imbedded audio) One way HD-SDI interface(Optional) One way HDMI interface(Optional) One way analog composite video signal RJ45 interface(Optional) Data interface can be provided |
| Parameter adjustable: | 1.The signal quality,strength can be displayed on the LCD screen 2.The frequency,bandwidth,guard interval are adjustable |
| Work environment: | Temperature:-30~70℃ Relative humidity:90% |
| Reserve environment: | Temperature:-40~80℃ Relative humidity:90% |
